Extensible grey electrical braided sheath diameter 6 to 14mm length 5 metres

Code: gaine-tresse-grise

Grey nylon sheath:

  • Easy to install
  • 3 diameters to choose from
  • 6, 10 and 14mm
  • Protection against chafing
  • Keeps cable trays together
  • Resistant to over 125°C
  • Professional finish
  • Sold in 5 metre lengths

8,3915,19

Extensible braided sheath for wiring harness


Grey nylon braided sleeving

Make your own electrical harnesses and cable trays using this stretchable sheath, which is easy to thread over your electrical wires.

Easy to install.

Choice of 3 diameters:

  • 6mm expandable up to 10mm
  • 10mm expandable to 14mm
  • 14mm expandable up to 20mm

Sold in 5-metre lengths.

Technical specifications:

  • Length: 5 metres
  • Colour: Grey
  • Material: Polyethylene (Nylon)
  • Maximum operating temperature: +125°C
  • Minimum operating temperature: -75°C
  • Resistant to chemicals, petrol, oil, E85, etc.
  • Protects against friction.
  • Helps keep cables grouped together.

Tip: For easier routing and handling, take care to braid your wires inside your sheaths,either using the “mil-spec” method, which is long and tedious but ensures a perfect result,or by twisting the wires by hand, which greatly increases the handling of your sheaths and harnesses.

Weight 0,1 kg
Diamètre

6mm, 10mm, 14mm
